ENG/Cart Mixing





Both are available in sales


Lectrosonics SMWB & SMDWB Miniature Wideband Transmitters

To meet the demand for both extended operating range and extended battery life, the “WB” series SM transmitters offer selectable output power of 25, 50 and 100 mW. With higher power output, the operating range is improved at the expense of battery life. When range is not an issue, a lower power level can be used to extend the battery life.


  • Selectable output power to maximize battery life or operating range
  • Ultra-lightweight, corrosion resistant housing
  • Water resistant seals for use in damp environments
  • LCD interface with lockout option
  • Programmable compatibility modes for use with a wide variety of different receivers
  • Servo Bias input circuitry
  • IR (infrared) port for fast setup
  • Covers 3 standard frequency blocks
  • Update firmware in the field via Micro SD card reader
  • Alternate use as recorder on internal microSDHC memory card




Lectrosonics SSM Micro Belt-Pack Transmitter



Available in sales


The SSM is ideal in theatrical or any other production where concealment in costuming is required. In spite of its tiny size, the transmitter offers an extensive feature set and performance on par with all of the Digital Hybrid Wireless® models.

Frequencies are selectable in 100 kHz or 25 kHz steps across a maximum tuning range of 76.7 MHz. This yields a total of 3072 available frequencies across three standard frequency blocks. The tuning range varies in other blocks to meet applicable frequency allocations.

  • Tunable across three standard frequency blocks (76.8 MHz)
  • Digital Hybrid Wireless® audio for compandor-free digital quality
  • Selectable 25 or 50 mW RF power
  • Compatibility modes for use with analog receivers
  • 25 or 100 kHz tuning steps for up to 3072 selectable frequencies
  • Wide range input gain control in 1 dB steps
  • Quick change Lithium-ion rechargeable battery
  • Audio coupled remote control
*Digital Hybrid Wireless™ is a revolutionary new design that combines 24-bit digital audio with an analog FM radio link to provide outstanding audio quality and the extended operating range of the best analog wireless systems. The design overcomes channel noise in a dramatically new way, digitally encoding the audio bitstream in the transmitter and decoding it in the receiver, yet sending the encoded information via an analog FM wireless link. This proprietary DSP algorithm eliminates a compandor circuit and its artifacts, and preserves the RF spectral footprint of analog FM designs to simplify multi-channel coordination with exisiting analog wireless systems.

Lectrosonics Venue2 Modular Receiver

The Venue 2 Receiver is a modular solution that effectively deals with a congested RF spectrum with a variety of options that allows a system configuration to be idealized for a particular installation or application.

  • Six-channel modular configuration
  • Ratio or Antenna Phase diversity reception
  • 3-block tuning for up to 76 MHz and 3072 synthesized UHF frequencies per receiver module
  • IR port for quick transmitter setup
  • DSP emulation modes for compatibility with analog wireless systems in addition to the Digital Hybrid mode
  • iQ™ dynamic tracking filters for enhanced RF performance
  • Wireless Designer™ setup and control software included
  • Talkback function with select transmitters
  • Ethernet, USB and RS-232 computer interface ports

The receiver is comprised of several components:

  • The master rack mount host assembly
  • Up to six receiver modules
  • Built-in antenna multicoupler with loop-thru output
  • Software for setup and control

Flexibility is the core concept of the design. The receiver modules can be operated separately, each with switched diversity reception for a total of six audio channels, or operated in pairs for more robust diversity reception with one audio channel per module pair. Combinations can also be used for special applications where some modules operate independently and others are paired.

The receiver modules are easy to change with no tools required. The wideband multicoupler allows the use of any frequency module in any position, except when modules are paired for ratio diversity reception.


Available in sales



Lectrosonics Duet M2T & M2TND Rack IEM/IFB Transmitters


M2T is Dante enabled



The M2T half-rack transmitter houses two stereo transmitters to provide two stereo audio channels, and for up to four mono audio channels in a single rack space. The audio inputs can be individually configured to be analog or Dante compatible. The analog input connectors are full-size XLR/TRS combo types for balanced line-level analog signals while the input preamp circuits use a special balanced amplifier with very high common mode rejection to minimize hum and noise. A Dante™ Ultimo™ interface via dual RJ45 connectors accepts Dante networked audio inputs and can cascade the digital stream to additional units via CAT6 cables. An additional RJ45 jack provides an Ethernet connection for programming and control via Wireless Designer™ software and a USB jack on the front panel allows for firmware updates. The transmitter features a full color, backlit LCD for high visibility in any environment, while the chassis is all-metal and can be racked singly or in pairs using included rack mount hardware.

  • IEM (Wireless Monitor) with digital RF transmission
  • 24-bit digital audio
  • 2 independent stereo audio transmissions per 1/2 RV enclosure
  • USB port for firmware updates
  • Fully Dante™ compatible
  • IR (infrared) port for fast setup
  • Up to 50 mW per Rf carrier
  • All metal housing
  • Compatible with Wireless Designer™ Software

Both are available in sales



Lectrosonics Duet M2R Beltpack Digital Stereo IEM/IFB Receiver

The M2R operates in the UHF frequencies of 470-608 MHz in a single range, using digital modulation for transmission.

The M2R bodypack receiver employs advanced antenna diversity switching during digital packet headers for seamless audio. The 24 bit digital audio stream guarantees high resolution sound quality with wide dynamic range, low noise floor, and rock-solid stereo image. The receiver can select from stereo, mono from left channel only, or mono from right channel only, giving the unit flexibility in terms of the application. The headphone jack is fed from a high-quality stereo amplifier with 250 mW available to drive headphones or earphones to sufficient levels for stage performance or other environments with significant background noise. A high-resolution, color LCD allows for a wide range of menu options, including precise limiter settings, using detailed graphics. The M2R runs on two AA batteries for an operating time of over 4 hours with alkaline cells.

  • IEM (Wireless Monitor) receiver with digital RF
  • 24-bit digital audio
  • IR (infrared) port for fast setup
  • High resolution, color LCD
  • Stereo or mono operation
  • Low latency of 1.4 ms with analog inputs


back to top



Available in sales




Lectrosonics SRc Dual-Channel Slot Mount ENG Receiver

The SRc5P and SRc consists of two separate receivers built into a single, ultra compact housing with adapters for video camera receiver slots and for stand-alone use. Digital Hybrid Wireless® technology provides superb, compandor-free audio quality and compatibility with other wireless systems. The RF performance is extremely stable over a very wide temperature range, making the receiver perfectly suited to the rough environmental conditions found in field production.

DSP compatibility modes allow the receiver to be used with a variety of Lectrosonics systems, other brands of wireless systems and with Lectrosonics IFB transmitters.

  • Fits camera “slots,” Lectrosonics Duopack adapter and Octopack multicoupler, and operates stand-alone with various adapters
  • 76 MHz tuning range in 100 kHz or 25 kHz steps for up to 3072 frequencies (bands A1, B1, C1)
  • 941 band offers 695 frequencies over 19 MHz tuning range with 25 kHz steps
  • Dual receiver design for two channels with phase switched diversity or single channel with ratio diversity operation
  • Digital Hybrid Wireless® with compatibility modes for use with other transmitters
  • Tracking front-end filters for high performance in tough RF environments
  • LCD with RF spectrum scanning
  • SmartSquelchTM DSP-controlled, noise based filtering and squelch
  • DSP-based pilot tone for squelch control
  • IR sync port for quick transmitter setup (LMb, LT, HHa, HMa, & SSM)
  • SmartTune operation for quick and confident frequency selection

Lectrosonics HMa Plug-On Transmitter

This unique plug-on transmitter design will ideally match any microphone or line level source via a standard XLR connector. Phantom power is selectable at 5, 15 and 48 volts, or can be turned off for use with dynamic microphones and line level signal sources.

The design includes a wide tuning range of up to 76 MHz, with tuning steps in increments of 100 kHz or 25 kHz for up to 3072 frequencies (19 MHz for block 941 version, for 695 frequencies).

DSP compatibility modes are also included to work with legacy Lectrosonics analog wireless microphone receivers and IFB receivers, as well as some receivers from other manufacturers.

Key Features and Benefits

  • Accepts microphone or line level signals
  • Selectable 5, 15, 48 volt phantom power
  • 76 MHz tuning range in 100 kHz or 25 kHz steps for up to 3072 frequencies (bands A1, B1, C1)
  • 941 band offers 695 frequencies over 19 MHz tuning range with 25 kHz steps
  • Selectable 50/100 mW output power
  • Adjustable low frequency roll-off
  • Powered by two AA batteries
  • USB port for firmware updates
  • IR (infrared) port for fast setup
  • Solid machined aluminum housing



back to top



Wisycom MAT288 Diversity Wideband Programmable Matrix Combiner

MAT 288 is a programmable diversity matrix combiner. This unique device allows you to combine RF coming from 8 areas (a couple of diversity feeds) on the fly thanks to a matrix of solid state switches. It is designed to have the greatest reliability, with a redundant power supply (AC and DC). All operations can be remote with Ethernet. Typical applications are a production center where a control room has to work with several STUDIOs also at the same time or a THEATRE that needs time to time to combine main stage, foyer or lobby. Also your ENG or OB-Van facility will benefit this freedom to manage different RF areas. This flexibility along with the possibility to work in wideband allows also an easy deployment of your wireless audio infrastructure and also to optimize your overall CAPEX (i.e. sharing resources like wireless microphones).

FEATURES

  • Diversity combiner 8:1 or 8:4 or 2 x 4:2 (sw configurable)
  • Wide bandwidth 150-840 MHz operation
  • Redundant power supply, AC and DC powered
  • Remote management and monitor of alarms thru Ethernet 10/100 base TX
  • Antenna booster supply toggled on each input independently
  • Voltage and current monitoring on each booster supply with alarm
  • Programmable attenuators on each inputs
  • Remote boost control (for gain/bandwidth) with a bidirectional data link through coax (input BNCs)
  • Light window where users can enter their own text to identify 8 areas

Available in sales


__Wisycom+Red Wave+PayOff.jpg


Wisycom MAT244 Wideband Programmable Matrix Combiner

MAT244 is very flexible combiner especially designed to manage RF in a multi-site production environment.

It can:
– route RF in several possible configurations
– control antenna remotely
– manage attenuation/boost for the different areas
– monitor RF and interference through an integrated RF meter

All of this can be done remotely thanks to an Ethernet interface and a very intuitive PC software.

MAT244 can be configure locally of by SW as a diversity combiner 4:2 with 6dB gain or in a non-diversity combiner 8:4 / 8:1

FEATURES

  • Combiner mode: diversity 4:2 / non-diversity 8:1 or 8:4 (SW configurable)
  • Wide bandwidth 150-840 MHz operation
  • Remote management and monitor of alarms thru Ethernet 10/100 base TX
  • Antenna booster supply toggled on each input independently
  • Voltage and current monitoring on each booster supply with alarm
  • Programmable attenuators on each inputs
  • Remote boost control (for gain/bandwidth) with a bidirectional data link through coax (input BNCs)
  • Light window where the user can enter their own text to identify the 8 areas

Available in sales


Wisycom MTB40S Plug-On Transmitter

MTB40S is an extremely small and light plug-on transmitter especially designed for professional wireless microphone applications.
MTB40S benefit of the latest Wisycom RF technology along with an enhanced robustness against noise and inter-modulation.
Improved features:
– New white OLED display
– New XLR locking system
– Integrated HW limiter

FEATURES

  • Up to 232 MHz bandwidth in 470/798 MHz range
  • Enhanced robustness against self-interferences and antenna performances thru a proprietary “intermodulation cancellation” circuit
  • Miniature design with flexible pcb (no connectors) for extended reliability
  • User selectable companding systems
    ENR (noise optimized)
    ENC (voice optimized)
  • Input dynamic extension with an integrated HW limiter (30 dB above peak)
  • P48 phantom power for condenser microphones
  • New white OLED display (128 x 32 pixels)
  • New XLR-3F connector with locking collar to ensuring an extremely tight noiseless fit!
  • Infrared interface for management and firmware update
  • Audio input circuitry with high linearity audio transformer
  • Battery: 2 AA Alkaline or rechargeable NiMH or Lithium

Available in sales




Wisycom LFA LDPA Antenna With Amplifier

LFA is a directional antenna with a unique design to achieve an ultra wide band of 410-1300 MHz, a compact and rugged form factor, and ample wind resistance reduction. LFA integrates a unique bank of filters along with a low-noise amplifier. Filters and gain can be easily setup locally through 4-key navigation buttons and a TFT display or remotely with a data connection on the same RF coaxial cable.

Using the latest Wisycom filter technology, LFA gives full control of RF zones and allows you to build flexible and remote controllable antenna systems.

FEATURES

  • Huge reception band: 410-1300 MHz
  • Remote controllable through coax cable
  • RF gain from -12 to +27 dBu (1 dB step)
  • Easy configuration through a TFT display
  • Tunable filter for interference control
  • Antenna off for RF zone disabling
  • Fixed band saw filter
  • Skeletal design for low wind loading
  • 3 High Pass & 3 Low Pass filters
  • Waterproof with gasket sealing

Available in sales




Wisycom LBNA2-LNNA2 Wideband Antenna with remote controlled filers

LBNA2/LNNA2 is a wideband UHF antenna LPDA (long periodic dipole array). It enhances reception providing approximately 6 dB gain with a typical beam-width of 90 degrees.

FEATURES

  • Agile: working bandwidth of 470-870 MHz
  • Easy & Quick to Use: LED display & function buttons
  • Ruggedized: sturdy metal body construction and epoxy protection on cable joints
  • High-Performing: optimized 6dB gain with a typical beam-width of 90 degrees
  • Booster-Integrated: very high linear booster (OIP3 40 dBm) with 15 dB gain settable in one step dB step



Wisycom ADN-ADB Omnidirectional Wideband Antenna

ADN/ADB is a wideband UHF omnidirectional antenna. It enhances reception providing approximately 3.2 dBi gain.

FEATURES

  • Agile: working bandwidth of 400-930 MHz
  • Ruggedized: sturdy metal body construction and epoxy protection on cable joints
  • High-Performing: optimized 3.2 dB gain


Wisycom MCR42S UHF Dual True-Diversity Miniature (Camera) Receiver

Wisycom’s MCR42 is a camera receiver designed for best-in-class performance.

Four receivers are internally coupled by two in a real true diversity configuration. Its front end has a chain of micro-controlled-driven movable filers to allow broadband operation up to 240 MHz with great selectivity.

A powerful low consumption DSP gives you the best of analogue and digital technologies in a hybrid approach for smooth operations and high coverage.

  • Dual true diversity in a modular stand-alone or slot-in format
  • Switching bandwidth up 240 MHz in the UHF range
  • DSP based audio processing digital outputs
  • Patented PTT (push to talk) integrated
  • 40 groups of 60 frequencies fully user programmable
  • Multicompander operations
  • Infrared interface for programming and transmitter synchronization
  • Wisycom exclusive digital sub-carrier telemetry technology allows:
         *Remote TX Battery Monitoring
         *Tone-Squelch Operating
         *PTT Function (*optional back-panel module is available with the secondary intercom output)
  • Easy set up and operation through an OLED display



Available in sales
